Max Clock Speed with Intel® Turbo Boost Technology 2.01
6 Cores
12 Threads
2.9GHZ
BASE CLOCK SPEED
12MB
INTEL® SMART CACHE
65W
TDP
Get more done with
Intel® Hyper-Threading Technology
Intel® HT Technology uses processor resources more efficiently, enabling multiple threads to run on each core. It increases processor throughput to improve overall performance, meaning it can run demanding applications simultaneously while maintaining system responsiveness. Intel® HT Technology is now available across the entire 10th Gen Intel® Core™ processor family, allowing you to multitask with confidence, and do more simultaneously, no matter which Intel® Core™ processor you choose.
Performance for Games & Entertainment
Featuring 6 Cores, 12 Threads and a base frequency of 2.9GHz, the Intel® Core™ i5-10400 has the power to drive a seamless gaming experience. Under load, the Core™ i5-10400 can push up to a 4.3 GHz clock speed with Intel® Turbo Boost Max Technology 2.0, providing power when you need it the most.
Level up your technology
Experience amazing gameplay and creativity with Intel¡¯s supported platform features. Get more from your PC build by untethering with Intel® Wi-Fi 6 (Gig+), versatile connectivity with Thunderbolt™ 3, and accelerated responsiveness with Intel® Optane™ memory.
Support Your Productivity
The i5-10400 features Intel® Hyper-Threading Technology, 6 Cores and 12 Threads to manage applications more efficiently, allowing you to drive your productivity and multi-tasking to accomplish more throughout your daily schedule.
WHICH ONE IS RIGHT FOR YOU?
Learn about Intel¡¯s new 10th Generation and decide which one suits your needs.
Choose your perfect fit
Wargaming.net (World of Tanks)
¡¡ãWith the 10th Generation of their Core® platform, Intel are once again pushing the boundaries of the modern CPU architecture. The performance boost compared to the predecessors will ensure the World of Tanks Core engine fully unleashes its potential in Ray Tracing and other latest rendering technologies, allowing for deeper immersion and more enjoyable gameplay.¡¡À
Vladimir Ostapenko, Head of Development, World of Tanks.
Drive your experience with unique tech from Intel
Looking to start a live stream, but unsure how to start? Intel® Easy Streaming Wizard makes it easier than ever to get up and streaming with Open Broadcaster Software (OBS) in minutes, instead of hours.3
Specifications
Essentials
Product Collection
10th Generation Intel® Core™ i5 Processors
Code Name
Products formerly Comet Lake
Vertical Segment
Desktop
Processor Number
i5-10400
Status
Launched
Launch Date
Q2'20
Lithography
14 nm
Use Conditions
PC/Client/Tablet
Performance
# of Cores
6
# of Threads
12
Processor Base Frequency
2.90 GHz
Max Turbo Frequency
4.30 GHz
Cache
12 MB Intel® Smart Cache
Bus Speed
8 GT/s
TDP
65 W
Memory Specifications
Max Memory Size (dependent on memory type)
128 GB
Memory Types
DDR4-2666
Max # of Memory Channels
2
Max Memory Bandwidth
41.6 GB/s
ECC Memory Supported
No
Processor Graphics
Processor Graphics
Intel® UHD Graphics 630
Graphics Base Frequency
350 MHz
Graphics Max Dynamic Frequency
1.10 GHz
Graphics Video Max Memory
64 GB
4K Support
Yes, at 60Hz
Max Resolution (HDMI 1.4)
4096x2160@30Hz
Max Resolution (DP)
4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel)
4096x2304@60Hz
DirectX* Support
12
OpenGL* Support
4.5
Intel® Quick Sync Video
Yes
Intel® InTru™ 3D Technology
Yes
Intel® Clear Video HD Technology
Yes
Intel® Clear Video Technology
Yes
# of Displays Supported
3
Device ID
0x9BC8 / 0x9BC5
Expansion Options
Scalability
1S Only
PCI Express Revision
3.0
PCI Express Configurations
Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes
16
Package Specifications
Sockets Supported
FCLGA1200
Max CPU Configuration
1
Thermal Solution Specification
PCG 2015C
T JUNCTION
100¡ãC
Package Size
37.5mm x 37.5mm
Advanced Technologies
Intel® Optane™ Memory Supported
Yes
Intel® Thermal Velocity Boost
No
Intel® Turbo Boost Max Technology 3.0
No
Intel® Turbo Boost Technology
2.0
Intel® vPro™ Platform Eligibility
No
Intel® Hyper-Threading Technology
Yes
Intel® Virtualization Technology (VT-x)
Yes
Intel® Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® VT-x with Extended Page Tables (EPT)
Yes
Intel® Transactional Synchronization Extensions
No
Intel® 64
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States
Yes
Enhanced Intel SpeedStep® Technology
Yes
Thermal Monitoring Technologies
Yes
Intel® Identity Protection Technology
Yes
Intel® Stable Image Platform Program (SIPP)
No
Security & Reliability
Intel® AES New Instructions
Yes
Secure Key
Yes
Intel® Software Guard Extensions (Intel® SGX)
Yes with Intel® ME
Intel® OS Guard
Yes
Intel® Trusted Execution Technology
No
Execute Disable Bit
Yes
Intel® Boot Guard
Yes
